Self-adhesive Butyl Waterproofing Sheet
Self-adhesive waterproof sheet for building exterior walls, rooftops, and underground structures. Provides a continuous moisture barrier with exceptional peel strength and durability.
Key Specifications
| Width | 1,000mm ~ (Custom) |
| Thickness | 1mm ~ 2mm |
| Peel Strength | ≥ 10 N/25mm |
| Operating Temp | -40°C to +120°C |
| Roll Length | 10m / 20m |
Product Overview
Garmy Butyl Sheet is a large-format self-adhesive waterproofing membrane designed for broad-area coverage in construction applications. Its dual-layer structure combines a butyl rubber adhesive layer with a protective backing for enhanced mechanical strength. Ideal for rooftop waterproofing, below-grade moisture barriers, and exterior wall vapor control.
Key Features
- ✓Self-adhesive butyl adhesive layer + functional HDPE film
- ✓Full-surface adhesion without mechanical fasteners
- ✓Cold-applied — no torch or heat required
- ✓Excellent elongation for crack-bridging capability
- ✓Resistant to root penetration for green roof applications
- ✓UV-stabilized top surface option available
- ✓Compatible with concrete, metal, and wood substrates
- ✓KS F 4935 compliant
Technical Specifications
All specifications tested per ASTM / KS standards. Custom formulations available upon request.
| Application | Specific Gravity | Heat Resistance | Cold Resistance |
|---|---|---|---|
| Building structures (rooftops, underground parking, upper slabs) / Civil structures (underpasses, subways, utility tunnels) / Other structures requiring waterproofing (metal, wood, panel) | 1.40 – 1.65 | 120°C | -40°C |
Applicable Standards
Relevant test methods and compliance standards by region.
| Region | Standards |
|---|---|
| US |
|
| AU / NZ |
|
| EU |
|
| UK |
|
| Japan |
|
Industry Applications
Self-adhesive Butyl Waterproofing Sheet is trusted across major industries for its versatility and reliable performance.
Construction
Full-surface waterproofing membrane for rooftops, basements, and building envelopes.
- •Flat roof waterproofing
- •Below-grade foundation walls
- •Exterior wall moisture barrier
- •Green roof base layer
- •Tunnel lining waterproofing
Quality Certifications
All Garmy products are manufactured under internationally recognized quality management systems.
