Vibration Damping Pad
Anti-vibration pad engineered for automotive roof panels, fender linings, and HVAC systems. Reduces NVH (noise, vibration, harshness) with consistent performance across temperature extremes.
Key Specifications
| Density | 2.0 ~ 3.5 kg/m² |
| Loss Factor | ≥ 0.15 (200Hz, 20°C) |
| Operating Temp | -40°C to +110°C |
| Form | Die-cut Pad / Sheet |
Product Overview
Garmy Vibration Damping Pad is a butyl rubber-based constrained-layer damping material specifically designed for the automotive industry. Applied to sheet metal panels, it converts vibrational energy into heat, significantly reducing cabin noise and improving ride comfort. Supplied to Hyundai, Kia, and GM as a Tier 1 approved material.
Key Features
- ✓High loss factor for effective NVH reduction
- ✓Self-adhesive backing for easy panel application
- ✓Custom die-cut shapes for specific panel geometries
- ✓Odorless and low-VOC formulation
- ✓Hyundai/Kia/GM Tier 1 approved
- ✓IATF 16949 & Hyundai SQ certified
Technical Specifications
All specifications tested per ASTM / KS standards. Custom formulations available upon request.
| Application | Specific Gravity | Heat Resistance | Cold Resistance |
|---|---|---|---|
| Automotive ROOF / FENDER PANEL — noise & vibration damping | 1.65 ± 0.1 | 110°C | -40°C |
Applicable Standards
Relevant test methods and compliance standards by region.
| Region | Standards |
|---|---|
| Global Automotive |
|
| Korea OEM |
|
| EU |
|
| Japan |
|
Industry Applications
Vibration Damping Pad is trusted across major industries for its versatility and reliable performance.
Automotive
NVH reduction for vehicle body panels, underbody, and interior assemblies.
- •Roof panel damping
- •Fender and wheel house panels
- •Floor panel vibration control
- •Door inner panel
- •Trunk and tailgate panels
Electronics
Vibration and noise control for home appliances, HVAC units, and industrial equipment.
- •HVAC compressor housing
- •Washing machine drum panel
- •Generator enclosure
- •Industrial fan housing
Quality Certifications
All Garmy products are manufactured under internationally recognized quality management systems.
